2019 Infiniti Q70

large luxury car / 4-door sedan

2019 Infiniti Q70 4-door sedan
2015 Infiniti Q70 shown

Crashworthiness

Rating overview
Small overlap front: driver-side
Moderate overlap front: original test
Side: original test
Roof strength
Head restraints & seats

Crash avoidance & mitigation

Headlights (varies by trim/option)
Front crash prevention: vehicle-to-vehicle
Optional system
Superior

Seat belts & child restraints

LATCH ease of use

Other available safety features

  • Optional blind spot detection
  • Optional lane departure warning
  • Optional lane departure prevention

Key

  • G
    Good
  • A
    Acceptable
  • M
    Marginal
  • P
    Poor
  • Superior
  • Advanced
  • Basic

Some ratings use a scale of Poor to Good. Others range from Basic to Superior.

Small overlap front: driver-side

Rating applies to 2014-19 models

Tested vehicle: 2014 Infiniti Q70 3.7 4-door

The Infiniti M sedan was renamed the Infiniti Q70 beginning with the 2014 model year, available with V6, V8, and hybrid V6 powertrains. Starting with 2013 M models, design changes were made to the frontal airbags and seat belts; no additional substantive changes were made with the model name change for 2014.

Overall evaluation
Structure and safety cage
Driver injury measures
Head/neck
Chest
Hip/thigh
Lower leg/foot
Driver restraints and dummy kinematics

Action shot taken during the small overlap frontal crash test.

The dummy's position in relation to the door frame, steering wheel, and instrument panel after the crash test indicates that the driver's survival space was maintained reasonably well.

The frontal and side curtain airbags worked well together to keep the head from coming close to any stiff structure or outside objects that could cause injury.

Except for door hinge pillar deformation and intrusion of the parking brake pedal (not visible), the driver's space was maintained reasonably well, and risk of injuries to the dummy's legs and feet was low.

Technical measurements for this test

Measures of occupant compartment intrusion on driver side

Test ID CEN1431
Lower occupant compartment
Lower hinge pillar max (cm) 15
Footrest (cm) 14
Left toepan (cm) 9
Brake pedal (cm) 7
Parking brake (cm) 22
Rocker panel lateral average (cm) 10
Upper occupant compartment
Steering column 0
Upper hinge pillar max (cm) 8
Upper dash (cm) 8
Lower instrument panel (cm) 9

Driver injury measures

Test ID CEN1431
Head
HIC-15 109
Peak gs at hard contact no contact
Neck
Tension (kN) 0.8
Extension bending moment (Nm) 7
Maximum Nij 0.15
Chest maximum compression (mm) 26
Femur (kN)
Left 2.5
Right 1.1
Knee displacement (mm)
Left 4
Right 2
Knee-thigh-hip injury risk (%)
Left 0
Right 0
Maximum tibia index
Left 0.68
Right 0.52
Tibia axial force (kN)
Left 1.8
Right 2.2
Foot acceleration (g)
Left 90
Right 55

About the small overlap front test

Moderate overlap front: original test

Rating applies to 2014-19 models

Tested vehicle: 2013 Infiniti M37 Premium 4-door 4wd

Beginning with the 2014 model year, the Infiniti M sedan was renamed the Infiniti Q70, available with V6, V8, and hybrid V6 powertrains.

The Infiniti M sedan was redesigned for the 2011 model year and renamed the M37 and M56 at that time because the sizes of the two available engines were increased. A hybrid-electric version of the M, known as the M Hybrid, was introduced in the 2012 model year. Beginning with 2013 models, design changes were made to the frontal airbags and seat belts.

Two moderate overlap frontal tests of the M were conducted by Nissan, one of a 2011 model and the other representing a 2013 model. These cars are rated separately, except that the structure ratings for both vehicles are based on both tests. (The second car tested by Nissan was designated as a 2012 model but included the airbag and seat belt changes of the 2013 models.)

Overall evaluation
Structure and safety cage
Driver injury measures
Head/neck
Chest
Leg/foot, left
Leg/foot, right
Driver restraints and dummy kinematics
Technical measurements for this test

Measures of occupant compartment intrusion on driver side

Test ID VTF0912 VTF1123
Footwell intrusion
Footrest (cm) 4 7
Left (cm) 8 9
Center (cm) 11 12
Right (cm) 11 12
Brake pedal (cm) 11 16
Instrument panel rearward movement
Left (cm) 1 1
Right (cm) 2 1
Steering column movement
Upward (cm) 5 0
Rearward (cm) -1 1
A-pillar rearward movement (cm) 0 0

Driver injury measures

Test ID VTF1123
Head
HIC-15 491
Peak gs at hard contact 89
Neck
Tension (kN) 1.3
Extension bending moment (Nm) 25
Maximum Nij 0.28
Chest maximum compression (mm) 32
Legs
Femur force - left (kN) 0.5
Femur force - right (kN) 3.6
Knee displacement - left (mm) 2
Knee displacement - right (mm) 1
Maximum tibia index - left 0.32
Maximum tibia index - right 0.63
Tibia axial force - left (kN) 1.6
Tibia axial force - right (kN) 2.7
Foot acceleration (g)
Left 84
Right 119

About the original moderate overlap front test

Side: original test

Rating applies to 2014-19 models

Tested vehicle: 2013 Infiniti M56 Premium 4-door 4wd with standard front and rear head curtain airbags and standard front seat-mounted torso airbags

Beginning with the 2014 model year, the Infiniti M sedan was renamed the Infiniti Q70, available with V6, V8, and hybrid V6 powertrains.

The Infiniti M sedan was redesigned for the 2011 model year and renamed the M37 and M56 at that time because the sizes of the two available engines were increased. A hybrid-electric version of the M, known as the M Hybrid, was introduced in the 2012 model year. Beginning with 2013 models, design changes were made to the seat-mounted side torso airbags to improve occupant protection in side impact crashes.

Two side tests of the M were conducted by Nissan, one a 2011 M37x and the other a 2013 M56x. These cars are rated separately, except that the structure ratings for both vehicles are based on both tests, as are rear dummy injury and head protection ratings, because no changes were made to the rear occupant compartment.

Overall evaluation
Structure and safety cage
Driver injury measures
Head/neck
Torso
Pelvis/leg
Driver head protection
Rear passenger injury measures
Head/neck
Torso
Pelvis/leg
Rear passenger head protection
Technical measurements for this test

Measures of occupant compartment intrusion on driver side

Test ID VTS0910 VTS1223
B-pillar to longitudinal centerline of driver's seat (cm) -11.0 -10.5
Negative numbers indicate the amount by which the crush stopped short of the seat centerline.

Driver injury measures

Test ID VTS1223
Head HIC-15 267
Neck
Tension (kN) 0.9
Compression (kN) 0.4
Shoulder
Lateral deflection (mm) 34
Lateral force (kN) 1.5
Torso
Maximum deflection (mm) 30
Average deflection (mm) 25
Maximum deflection rate (m/s) 2.97
Maximum viscous criterion (m/s) 0.31
Pelvis
Iliac force (kN) 1.7
Acetabulum force (kN) 1.9
Combined force (kN) 3.4
Left femur
L-M force (kN) 0.4
L-M moment (Nm) 28
A-P moment (Nm) -93

Passenger injury measures

Test ID VTS0910 VTS1223
Head HIC-15 194 176
Neck
Tension (kN) 0.2 0.1
Compression (kN) 0.8 0.9
Shoulder
Lateral deflection (mm) 48 52
Lateral force (kN) 2.0 2.0
Torso
Maximum deflection (mm) 32 35
Average deflection (mm) 20 22
Maximum deflection rate (m/s) 3.56 3.95
Maximum viscous criterion (m/s) 0.40 0.52
Pelvis
Iliac force (kN) 0.5 0.5
Acetabulum force (kN) 1.5 1.3
Combined force (kN) 1.9 1.7
Left femur
L-M force (kN) 0.4 0.4
L-M moment (Nm) 34 25
A-P moment (Nm) 68 76

About the original side crash test

Roof strength

Rating applies to 2014-19 models

Tested vehicle: 2011 Infiniti M37 4-door

Rating does not apply to V8 4-wheel drive models. Rating of these models is Acceptable.

Overall evaluation
Curb weight3,821 lbs
Peak force16,085 lbs
Strength-to-weight ratio4.21

About the roof strength test

Head restraints & seats

Seat type: Power leather seat

Overall evaluation
Dynamic rating
Seat/head restraint geometry
Technical measurements for this test
Seat type Power leather seat
Geometry
Backset (mm) 51
Distance below top of head (mm) 54
Seat design parameters
Pass/fail Pass
Max T1 acceleration (g) 11.8
Head contact time (ms) 68
Force rating 1
Neck forces
Max neck shear force (N) 22
Max neck tension (N) 706

About the head restraint & seat test
Currently, IIHS tests apply only to front seats.

Headlights

Ratings are given for 2 different headlight variations available on this vehicle.

Trim level(s)

  • 3.7 LUXE trim
  • 5.6 LUXE trim
Low-beam headlight typeLED projector
High-beam headlight typeLED reflector
Curve-adaptive?No
High-beam assist?No
Overall rating
Distance at which headlights provide at least 5 lux illumination:
car-simpler car-simpler car-simpler car-simpler car-simpler 0 ft 100 ft 200 ft 300 ft 400 ft 500 ft 600 ft Low beams Optimal low-beam illumination High beams Optimal high-beam illumination

Low beams
On the straightaway, visibility was good on the right side of the road and fair on the left side. On curves, visibility was fair on the sharp left and both right curves and inadequate on the gradual left curve.

The low beams never exceeded glare limits.

High beams
On the straightaway, visibility was good on the right side of the road and inadequate on the left side. On curves, visibility was fair on the gradual right and gradual left curves and inadequate on the sharp left and sharp right curves.

Technical measurements for this test
Trim level(s)
  • 3.7 LUXE trim
  • 5.6 LUXE trim
Low-beam headlight type LED projector
High-beam headlight type LED reflector
Curve-adaptive? No
High-beam assist? No
Overall rating
Applies to 2016-19 models
LOW BEAMS Average minimum useful
illumination distance (5 lux)		 Amount glare
exceeded threshold
Straightaway right edge 99.1 m None
Straightaway left edge 54.8 m None
250m radius right curve, right edge 62.3 m None
250m radius left curve, right edge 49.9 m None
150m radius right curve, right edge 46.0 m None
150m radius left curve, left edge 47.0 m None
HIGH BEAMS Average minimum useful
illumination distance (5 lux)
Straightaway right edge 148.8 m
Straightaway left edge 122.1 m
250m radius right curve, right edge 68.6 m
250m radius left curve, left edge 67.9 m
150m radius right curve, right edge 47.7 m
150m radius left curve, left edge 49.7 m

Trim level(s)

  • 3.7 LUXE trim equipped with ProACTIVE package
  • 5.6 LUXE trim equipped with ProACTIVE package
Low-beam headlight typeLED projector
High-beam headlight typeLED reflector
Curve-adaptive?Yes
High-beam assist?No
Overall rating
Distance at which headlights provide at least 5 lux illumination:
car-simpler car-simpler car-simpler car-simpler car-simpler 0 ft 100 ft 200 ft 300 ft 400 ft 500 ft 600 ft Low beams Optimal low-beam illumination High beams Optimal high-beam illumination

Low beams
On the straightaway, visibility was fair on both sides of the road. On curves, visibility was good on both right curves, fair on the sharp left curve and inadequate on the gradual left curve.

The low beams never exceeded glare limits.

High beams
On the straightaway, visibility was fair on the right side of the road and inadequate on the left side. On curves, visibility was fair on the gradual left and both right curves and inadequate on the sharp left curve.

Technical measurements for this test
Trim level(s)
  • 3.7 LUXE trim equipped with ProACTIVE package
  • 5.6 LUXE trim equipped with ProACTIVE package
Low-beam headlight type LED projector
High-beam headlight type LED reflector
Curve-adaptive? Yes
High-beam assist? No
Overall rating
Applies to 2016-19 models
LOW BEAMS Average minimum useful
illumination distance (5 lux)		 Amount glare
exceeded threshold
Straightaway right edge 81.3 m None
Straightaway left edge 47.1 m None
250m radius right curve, right edge 65.4 m None
250m radius left curve, left edge 47.2 m None
150m radius right curve, right edge 58.7 m None
150m radius left curve, left edge 45.1 m None
HIGH BEAMS Average minimum useful
illumination distance (5 lux)
Straightaway right edge 139.4 m
Straightaway left edge 123.2 m
250m radius right curve, right edge 72.7 m
250m radius left curve, left edge 65.8 m
150m radius right curve, right edge 59.5 m
150m radius left curve, left edge 48.2 m

About the headlight evaluation

Front crash prevention: vehicle-to-vehicle

System details

  • Optional Forward Emergency Braking

Package name

  • Optional Technology Package

Overall evaluation

Applies to 2015-19 models

Superior
Superior
with optional equipment
  • This system meets the requirements for forward collision warning.
  • In the 12 mph test, this vehicle avoided a collision.
  • In the 25 mph test, impact speed was reduced by 22 mph.

About the original front crash prevention test

Child seat anchors

Rating applies to 2016-19 models

Overall evaluation
Vehicle trim3.7
Seat type leather

This vehicle has 2 rear seating positions with complete child seat attachment (LATCH) hardware.

It has 1 additional seating position with a tether anchor only.

Overall evaluation
Vehicle trim3.7
Seat type leather
1 2 3
GGood
AAcceptable
MMarginal
PPoor
Seating positions that rely on borrowed lower anchors or have only a tether anchor available are not rated.
thether anchor symbol
Tether anchor
lower anchor symbol
Lower anchors
shared lower achors symbol
Lower anchor(s) can be borrowed from adjacent positions(s)
No hardware available

Details by seating position

1
Tether anchor
easy-to-find location
no other hardware could be confused for anchor
Lower anchors
too deep in seat
too much force needed to attach
difficult to maneuver around anchors
2
Tether anchor
easy-to-find location
no other hardware could be confused for anchor
Lower anchors
none available
3
Tether anchor
easy-to-find location
no other hardware could be confused for anchor
Lower anchors
too deep in seat
not too much force needed to attach
easy to maneuver around anchors
Technical measurements for this test

Seat position 21

3

Lower anchor A
Open access rated No
Depth (cm) 2-4
Force (lbs) 39
Clearance angle (degrees) 60
Lower anchor B
Open access rated No
Depth (cm) 4-6
Force (lbs) 34
Clearance angle (degrees) 75
Tether anchor
Location Rear deck
Confusing hardware present No
Has contrasting label
within 3 inches of tether anchor		 No
Tether anchors can be accessed
while seatback is properly positioned
for use of LATCH		 Not measured

Seat position 22

2

Lower anchor A
No lower latch for this seat position
Lower anchor B
No lower latch for this seat position
Tether anchor
Location Rear deck
Confusing hardware present No
Has contrasting label
within 3 inches of tether anchor		 No
Tether anchors can be accessed
while seatback is properly positioned
for use of LATCH		 Not measured

Seat position 23

1

Lower anchor A
Open access rated No
Depth (cm) 4-6
Force (lbs) 23
Clearance angle (degrees) 57
Lower anchor B
Open access rated No
Depth (cm) 4-6
Force (lbs) 44
Clearance angle (degrees) 52
Tether anchor
Location Rear deck
Confusing hardware present No
Has contrasting label
within 3 inches of tether anchor		 No
Tether anchors can be accessed
while seatback is properly positioned
for use of LATCH		 Not measured

About the child seat anchor evaluation
