2014 Nissan Titan
large pickup / Crew cab pickup
Moderate overlap front: original test
Rating applies to 2013-15 models
Tested vehicle: 2013 Nissan Titan S King Cab
The Nissan Titan was introduced in the 2004 model year. Beginning with 2013 models, design changes were made to the frontal airbags and seat belts. Moderate overlap frontal ratings are assigned by the Institute based on a test conducted by Nissan. (The vehicle tested by Nissan was designated as a 2012 model but included the airbag and seat belt changes of the 2013 models.) Because the vehicle structure did not change after 2004, structure ratings are based this test as well as an earlier test of a 2004 Titan conducted by the Institute.
| Overall evaluation | |
|---|---|
| Structure and safety cage | |
| Driver injury measures | |
| Head/neck | |
| Chest | |
| Leg/foot, left | |
| Leg/foot, right | |
| Driver restraints and dummy kinematics |
Measures of occupant compartment intrusion on driver side
| Test ID | CEF0412 | VTF1218 |
|---|---|---|
| Footwell intrusion | ||
| Footrest (cm) | 13 | 12 |
| Left (cm) | 14 | 14 |
| Center (cm) | 19 | 20 |
| Right (cm) | 15 | 15 |
| Brake pedal (cm) | 11 | 14 |
| Instrument panel rearward movement | ||
| Left (cm) | 4 | -3 |
| Right (cm) | 3 | 0 |
| Steering column movement | ||
| Upward (cm) | 9 | 6 |
| Rearward (cm) | 0 | 1 |
| A-pillar rearward movement (cm) | 4 | 4 |
Driver injury measures
| Test ID | VTF1218 | |
|---|---|---|
| Head | ||
| HIC-15 | 607 | |
| Peak gs at hard contact | 119 | |
| Neck | ||
| Tension (kN) | 1.5 | |
| Extension bending moment (Nm) | 34 | |
| Maximum Nij | 0.31 | |
| Chest maximum compression (mm) | 42 | |
| Legs | ||
| Femur force - left (kN) | 2.7 | |
| Femur force - right (kN) | 1.5 | |
| Knee displacement - left (mm) | 0 | |
| Knee displacement - right (mm) | 0 | |
| Maximum tibia index - left | 0.38 | |
| Maximum tibia index - right | 0.72 | |
| Tibia axial force - left (kN) | 2.8 | |
| Tibia axial force - right (kN) | 4.3 | |
| Foot acceleration (g) | ||
| Left | 118 | |
| Right | 107 | |
Roof strength
Rating applies to 2004-15 models
Tested vehicle: 2011 Nissan Titan Crew Cab
Rating applies to Crew Cab models, except for 4wd Crew Cab long bed model. Rating of this model is Marginal.
| Overall evaluation | |
|---|---|
| Curb weight | 5,008 lbs |
| Peak force | 17,847 lbs |
| Strength-to-weight ratio | 3.56 |
Head restraints & seats
Seat type: Power cloth seats AHR
| Overall evaluation | |
|---|---|
| Dynamic rating | |
| Seat/head restraint geometry |
| Seat type | Power cloth seats AHR |
|---|---|
| Geometry | |
| Backset (mm) | 89 |
| Distance below top of head (mm) | 33 |
| Seat design parameters | |
| Pass/fail | Pass |
| Max T1 acceleration (g) | 10.3 |
| Head contact time (ms) | 59 |
| Force rating | 1 |
| Neck forces | |
| Max neck shear force (N) | 36 |
| Max neck tension (N) | 499 |
About the head restraint & seat test
Currently, IIHS tests apply only to front seats.
